BZW-HW02 HSD Elbow outer terminal crimping machine
Product Detail

NO.1 For assembly of HSD 90° rear cover and outer conductor and visual inspection of

appearance after crimping.

NO.2 The main process is to cut the plate material cap and detect the crimp size of the

outer conductor.

NO.3 The machine cycle time is ≤6S, and the product pass rate is ≥98.5%.

NO.4 The touch screen operating system has a simple and reasonable operating interface,

which can quickly master the operation of the machine. All parameters can be easily set and

stored. The operation instructions are intuitive and simple to display with images

Application90° HSD outer terminalPower220V 50/60Hz
Air supply0.5-0.7MpaWeight260kg
Motor3000wDimension800*900*2000mm
Inquire Now
Name: *
Mobile:
E-mail: *
Message: *
Verification code: *

Other products
Hot products

FAQs aboutBZW-HW02 HSD Elbow outer terminal crimping machine

What types of wire harness processing machines do you offer?

We offer wire/cable processing lines (FAKRA, HSD, Ethernet, HV), terminal crimping machines, cutting & stripping machines, coaxial strippers, special machines (wire winding, tube cutting, shield net, ultrasonic welding), and auxiliary equipment (pre-f

What is the lead time for this machine?

Standard models typically ship within 30–45 days after order confirmation. Customized machines may require 45–60 days depending on configuration and options. We will provide an exact delivery schedule in your quotation.

Do you provide installation and training support?

Yes. We offer remote video commissioning and online training for all machines. On-site installation and training services are also available upon request. Our engineers will guide your team through setup, parameter setting, and trial production until the

Can this machine be customized for my specific wire or connector?

Yes. Our machines support flexible customization including wire gauge range, strip length, terminal type, connector housing, and integration with your existing production line or MES system. You can send us cable samples and drawings, and we will tailor t

What certifications do your wire harness processing machines have?

We have successively passed ISO9001, iso45001, ISO14001, iso50001, CE, TUV and other certifications, supported by advanced production equipment.
