NO.1 The machine uses PLC control, fiber communication, full servo s ystem and stable working performance.
NO.2 Touch screen control and parameters can be saved, it also can use the work sheet for production
NO.3 It Mainly uses world famous components brands to ensure the machine stability.
NO.4 The machine is installed with OES to monitor the crimping force during the production.
NO.5 Formula database system, storage one-key switching, operation authority management, product data tracking.
NO.6 Products with similar processing technology: Rosenberg H-MTD series, Aptiv H-MTD series, TE GEMnet (domestic terminal) series,
Hulian H-MTD series, Xianglong Jiaye H-MTD series, Huawei H-MTD series, Amphenol H-MTD series, Amphenol VE NET180°/90° 10 Gigab
it Ethernet, Kangsuo H-MTD series (applicable wires: GG251, Leoni 686-3, Leoni 647-4, Flowserve Cable, Lingya Cable, etc.).
| Wire OD range | Φ3.5-4.5mm |
| Wire length | 150-10000mm (Other length can be customerized made) |
| Capacity | ≤5s/pcs |
| Crimp force | 30KN |
| Power | 380V 50/60Hz |
| Air pressure | 0.5Mpa-0.7Mpa 8m3/h |
| Weight | about 2000kg |
| Dimension | 3600×1000×2200mm |
| Inspect | wire feed、cable angle detection、crimping check、air pressure inspect. |
| Applied applicator | OTP applicator, European mechnical applicator and pneumatic applicator. |
| Function | Pay-off zero cutting、wire jacket stripping、visual inspection of wire、angle adjustment、shield ring crimping、half stripped skin、flipping shielding wire、inner conductor stripping and crimping、NG check (it can be customerized made)、wire receiving (it can be customerized made) |
