BZW-3W Shield net combing machine

Defects liability period:12 Months
Degree of automation:Automatic
Transport package:Wooden Case
Specifications:700*500*430mm
Certificate:CE/ISO:9001/ISO45001
Trademark:bozhiwang
Country of origin:Changzhou, China

img of BZW-3W Shield net combing machine
img of detail_inquiryInquire Now
WHAT ARE YOU LOOKING FOR?
*
This field is required
Total quantity you need
*
This field is required
*
This field is required
Email format error
Due to email instability, you might miss our correspondence. Please provide your phone number for alternative contact.
This field is required
Telephone information is wrong!
Send Message
img of mask_layer_close
img of BZW-3W Shield net combing machine
Product Detail


Product Discription:

BZW-3W is a shield net cutting machine, mainly used to cut shield net of different types of cables, the processing range is 4mm-70mm2, and the cutting length can be set freely. The machine is characterized by a pure mechanical design scheme, which can be used without any electrical access, convenient, safe and fast. It Will not damage the cable insulation.

Tips: It is recommended that you provide the corresponding cable samples for us to test

Product Feature:

1.All working areas of the machine are visible;
2.When replacing the wire, just replace the matching cutting pipe and conduit;
3.Simple mechanical structure, high flexibility;
4.The machine is more secure without electrical access.

Technical Parameters :

BZW-3WShield net combing machine
Wire range4-70mm²(Shield net OD φ3-16mm)
Cutting length5-100mm
Powermanual pressure cutting
Power supplyno power
Dimension420*110*236mm
Weight6Kg
Inquire Now
Name: *
Mobile:
E-mail: *
Message: *
Verification code: *

Other products
Hot products

FAQs aboutBZW-3W Shield net combing machine

What types of wire harness processing machines do you offer?

We offer wire/cable processing lines (FAKRA, HSD, Ethernet, HV), terminal crimping machines, cutting & stripping machines, coaxial strippers, special machines (wire winding, tube cutting, shield net, ultrasonic welding), and auxiliary equipment (pre-f

What is the lead time for this machine?

Standard models typically ship within 30–45 days after order confirmation. Customized machines may require 45–60 days depending on configuration and options. We will provide an exact delivery schedule in your quotation.

Do you provide installation and training support?

Yes. We offer remote video commissioning and online training for all machines. On-site installation and training services are also available upon request. Our engineers will guide your team through setup, parameter setting, and trial production until the

Can this machine be customized for my specific wire or connector?

Yes. Our machines support flexible customization including wire gauge range, strip length, terminal type, connector housing, and integration with your existing production line or MES system. You can send us cable samples and drawings, and we will tailor t

What certifications do your wire harness processing machines have?

We have successively passed ISO9001, iso45001, ISO14001, iso50001, CE, TUV and other certifications, supported by advanced production equipment.
